Construction Mapping, Based in Las Vegas
Construction site mapping, delivered in days
High-resolution aerial capture processed to planning grade. Orthomosaics, 3D models, contours, and cut/fill volumes, tied to ground control and turned around on a fixed schedule.
What We Do
Services
Planning-grade capture and processing for construction, engineering, and land development teams across Nevada, Northern Arizona, and Southern Utah.
Site Mapping & Topo
Orthomosaics, contours, and volume reporting tied to ground control placed on site.
3D Mapping
Textured mesh, classified point cloud, and surface models built from planning-grade capture.
Infrastructure Inspections
High-resolution capture of towers, structures, and assets that are unsafe or slow to reach on foot.
Also available: aerial progress photography for documentation and records, and consulting to work out which deliverable you actually need before anyone books a flight.
DELIVERABLES
What you receive
Planning-grade outputs in the formats your team already works in.
Volume & cut/fill reports
Orthomosaic
Contours & linework
Surface & terrain models
Point cloud & 3D mesh
Drag to compare. 572 images processed at 1.4 cm/px ground sample distance.
Recent Work
Tracking a 54-acre subdivision as it builds out
Repeat flights over an active residential subdivision in the Las Vegas valley, turned into orthomosaics and a running record of progress.
Site
54-acre subdivision
Active residential construction in the Las Vegas valley: graded pads, streets, and drainage, all captured in one flight.
Output
An orthomosaic every visit
A fresh, scale-consistent image of the whole site from each flight, ready to measure from.
Comparison
Visit-to-visit progress
Repeat flights lined up against each other, so you can see what was graded, poured, or built between visits.
About this data
These are our own flights, not a paid client project. We fly this site to build and test the progress-tracking workflow we offer, so we show it for what the outputs look like, not as an accuracy claim. Client work adds surveyed ground control and a QC report.
How It Works
From site walk to deliverables
A repeatable four-step workflow, with no surprises between the quote and the handoff.
STA 0+00
Scope & flight plan
We define the boundary, set accuracy targets, place ground control points, and secure airspace clearances.
STA 1+00
Field capture
Ground control is placed and surveyed, then the site is flown in a single mobilization.
STA 2+00
Processing & QC
Imagery is processed, tied to control, and every output is checked before it leaves the shop.
STA 3+00
Delivery
Files land in your formats, with a QC report stating the accuracy achieved on your site.
Weather policy
Weather is the one thing we cannot put on a schedule. We do not fly in sustained winds above 20 mph or ground temperatures above 104°F, because the data suffers before the aircraft does. If a flight is scrubbed for weather or airspace, we fly it within 48 hours of conditions clearing, at no extra cost, and we keep your superintendent posted in the meantime.
Travel time
The day count above covers the work itself and excludes travel. Sites more than an hour's drive outside the Las Vegas valley add mobilization time between scoping and the flight, and we state the added days in writing when we confirm the schedule. Travel does not change processing, which still runs the day after capture.
Next Step
Send us a boundary, get a scoped quote
Two ways in, depending on how far along the project is. Either way you get a reply within one business day.
Scope defined
Send a full specification
Four short steps covering site, deliverables, coordinate system and schedule. Attach a boundary file and the number that comes back is a firm one.
Submit a SpecificationStill exploring
Just need a ballpark
Tell us roughly where the site is and what you need to measure, and we will come back with a range and the questions that would firm it up.
Quick InquiryPrefer to talk it through? Call 702-768-8299.
